ABOUT OUR FACILITY
Built for Precision PCB Manufacturing
Linked Electronics Co., Limited operates a comprehensive PCB manufacturing facility in China, equipped with advanced production lines for single-sided, double-sided, multilayer, HDI, heavy copper, aluminum, and rigid-flex PCB fabrication. Our facility supports the complete production workflow — from bare board fabrication through to finished, assembled, and tested PCBA.
Quality control is integrated at every stage. Automated optical inspection (AOI) verifies circuit patterns and detects defects. Drill hole inspection ensures precision alignment. Our FQC (Final Quality Control) room performs comprehensive electrical testing and visual inspection on every board before shipment.
Browse the photos below to take a virtual tour of the Linked Electronics Co., Limited PCB production facility.
